Mild Steel Pipe Specifications
| Standard | ASTM, IS, BS, or EN |
| Grades | ASTM A36, IS 2062, IS 1239 (Part I and II), BS 1387, and EN 10025. |
| Sizes | Nominal Bore (NB): Ranges from 1/2 inch to 24 inches Outside Diameter (OD): Common sizes range from 21.3 mm to 610 mm |
| Wall Thickness | valign="top"Varies depending on the pipe size and schedule (SCH), such as SCH 10, SCH 40, SCH 80, etc. |
| Length | Standard lengths: 6 meters or 12 meters Custom lengths available upon request |
| Shapes | Round, Square, Rectangular |
| Surface Finish | Black or Galvanized (GI), Painted or Powder Coated |
| Type | Seamless, ERW, Welded, Fabricated |
| End | Plain End, Beveled End, Treaded |
Mild Steel Characteristics
Mild steel belongs to the following category of low-carbon steel, with a small percentage of carbon, between 0. 05% and 0. 25%. This type of steel is highly ductile, making it easy to shape and weld. It's also cost-effective and easy to machine, so it's widely used in construction, automotive, and manufacturing industries.
Want to know more about mild steel? Click here.
Properties-
Chemical Composition
- Carbon (C): ≤ 0.25%
- Manganese (Mn): 0.25% to 0.70%
- Phosphorus (P): ≤ 0.05%
- Sulfur (S): ≤ 0.05%
- Other elements: Silicon (Si), Copper (Cu), Nickel (Ni), Chromium (Cr), etc.
Mechanical Properties
- Tensile Strength: Typically 330 - 540 MPa
- Yield Strength: Typically 205 - 345 MPa
- Elongation: 20% - 30%
Density
- Approximately 7.85 g/cm³
Quality assurance and material testing-
Mild steel pipes are subjected to thorough quality assurance and material testing, such as tensile strength, hardness, and impact tests. These tests ensure the pipes meet industry standards for durability and reliability, confirming their structural integrity and suitability for various uses. The quality checkers conducts different tests to check the quality of the MS Pipe. Some tests that are performed to check the quality of the product are-
- Hardness test
- Hydrostatic test
- Intergranular corrosion test
- Positive material identification
- Ultrasonic test
In addition to quality tests, the quality checkers perform different inspections. These include third-party inspection and visual inspection. These are carried out by a third-party inspection team comprising well-regarded experts in the field. They possess extensive knowledge about the manufacturing of the pipes that will be supplied to the clients. These tests and inspections are conducted to ensure that the clients are satisfied with the products they receive.
Documentation of the MS pipes-
Various documents related to the tests and the inspections are attached to the delivered MS Pipe to the clients. To ensure them that there are no harmful products is involved in the manufacturing of the pipes. The documents involved are-
- Commercial invoice
- Fumigation certificate
- Guarantee letter of the company
- Third-party inspection statement
- Visual inspection statement
- Raw material test report
Packing of the Mild Steel Pipes-
The MS Pipe is packed so that they don’t lose their properties and maintain their quality. These are well packed in the wooden boxes, pallets, and crates to prevent the pipes from getting rust during shipment of the pipes. They are even protected by the plastic cover so that they are not destroyed in the extreme weather conditions. We ensure the safe and fast delivery of the product to our clients.
Mild Steel Pipe Price
The price of mild steel pipes can vary based on factors such as size, grade, wall thickness, raw material, and market conditions. Prices also depend on specifications and quantities. We offer the largest selection of steel pipes available at wholesale prices. For specific requirements and bulk orders, contact us directly.
- Mild steel pipe price per kg in Gujarat : ₹65-₹75/kg
- 1/2 inch (15 mm) ms steel pipe - 150 Rs/kg
- 3/4 inch (20 mm) pipe - 154 Rs/kg
- 1 inch (25 mm) pipe - 152 Rs/kg
- 1 1/4 inch (32 mm) pipe - 162 Rs/kg
- 1 1/2 inch (40 mm) pipe - 168 Rs/kg
- 2 inch (50 mm) pipe - 175 Rs/kg
- 1/2 inch (15 mm) black ms pipe - 61 Rs/kg
- 1/2 inch (15 mm) galvanized ms pipe - 84.2 Rs/kg
- Galvanized steel pipes cost around 150-242 Rs/kg
- Black mild steel pipes cost around 61-100 Rs/kg
- 3" (80mm) ms pipes Price per Meter - ₹809 to ₹1101
- SCH 40 mild steel pipe 2" - $6.00 / meter
- Mild Steel Black Loha Pipe Price ₹ 45 -75/Kilogram
- 4 inch Schedule 80 mild steel pipe per foot $30 - $50
- MS Round pipes - Rs 72 /kg
- Schedule 40 Mild Steel Pipes : FOB Price in India: US $35.0 / Meters
- Black Iron schedule 40 mild pipes price on sale in stock
FOB Price in India: US $500-800 / Metric Ton
Mild Steel Pipe Sizes and Dimensions Confirming to IS : 1239 (PART I)
| Nominal Bore | Outside Diameter | Light (A-Class) Thickness Weight | Medium (B-Class) Thickness Weight | Heavy (C-Class) Thickness Weight | |||||
| Inch | mm | Inch | mm | mm | kg/mtr | mm | kg/mtr | mm | kg/mtr |
| 1/8″ | 3 mm | 0.406 | 10.32 | 1.80 | 0.361 | 2.00 | 0.407 | 2.65 | 0.493 |
| 1/4″ | 6 mm | 0.532 | 13.49 | 1.80 | 0.517 | 2.35 | 0.650 | 2.90 | 0.769 |
| 3/8″ | 10 mm | 0.872 | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.02 |
| 1/2″ | 15 mm | 0.844 | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.45 |
| 3/4″ | 20 mm | 1.094 | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.90 |
| 1″ | 25 mm | 1.312 | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.97 |
| 1.1/4″ | 32 mm | 1.656 | 42.90 | 2.65 | 2.580 | 3.25 | 3.140 | 4.05 | 3.84 |
| 1.1/2″ | 40 mm | 1.906 | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.43 |
| 2″ | 50 mm | 2.375 | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.17 |
| 2.1/2″ | 65 mm | 3.004 | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.90 |
| 3″ | 80 mm | 3.500 | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.1 |
| 4″ | 100 mm | 4.500 | 114.30 | 3.65 | 9.890 | 4.50 | 12.10 | 5.40 | 14.4 |
| 5″ | 125 mm | 5.500 | 139.70 | – | – | 4.85 | 16.20 | 5.40 | 17.8 |
| 6″ | 150 mm | 6.500 | 165.10 | – | – | 4.85 | 19.20 | 5.40 | 21.2 |
| Other Types of MS Pipes |
|---|
|
Types of MS Pipes
MS Square Pipe
MS Rectangular Pipe
Mild Steel Round Pipe
Mild Steel ERW Pipes
MS Seamless Pipe
MS Welded Pipe
MS Pipes Application
Mild steel pipes have a wide range of applications across various industries due to their durability, versatility, and affordability. Here are some of the key applications of mild steel pipes:
- Mild steel pipes are used in oil pipelines due to their low carbon content
- Mild steel pipes are used in boiler tubes
- MS black pipes are used in automotive exhaust systems
- MS steel square pipes are used in structural purpose
- MS Pipes uses in Water Supply Systems
- Mild steel pipes are used in fuel pipelines
- MS pipes are used in general building applications such as fencing, construction structure
- Mild steel pipes are used in gas pipelines due to their high strength, resistance to corrosion
- Mild steel round pipes are used in plumbing and water supply systems
